SFP-1.25G-BIDI 31/55nm 40KM

Model Name: CFTX-SFP-1.25G-BD40 Brand: CFTX, Package Type: SFP Rate: 1000Mbps, Wavelength: 1550nm-TX/1310nm-RX, Transmission Distance: 40km, Interface: LC/SC: Simplex Laser: DFB, BiDi, Fiber Type: Single-Mode, SMF, Digital Diagnostics (DDM/DOM), Yes/No, Transmit Optical Power: -3~2dBm, Receiver Sensitivity: < -23dBm, Commercial Temperature: 0~70°C (32~158°F), Extension Temperature: -5~85°C (23~185°F), Industrial Temperature: -40~85°C (-40~185°F) protocol fast

产品详情
资料下载

Compatible Model Name	SFP-1.25G-BD40	Vendor Name	CFTX
Form Factor	SFP	Data Rate	1000Mbps
Wavelength	1550nm-Tx/1310nm-RX	Max Transmission Distance	40km
Connector	Simplex-LC/SC	Media	Single mode-SMF
Transmitter power	-3~-2dBm	Receiver sensitivity	<-23dBm
DDM/DOM	Yes	Temperature Range	0~70°C（Commercial grade） /-40~85°C（Industrial grade）
Protocols	Fast Ethernet, Gigabit Fibre Channel, mobile communication systems	Laser Type	DFB
Compatible Brands	(Cisco)、Arista 、HUAWEI、ZTE、DLL、Intel、H3C、RuiJie、IBM、HP……
